YC-200 Herb Extractor
- 200L stainless steel extraction tank.
- Easy operation and simple control.
- Vacuum and atmospheric pressure operation.
- Versatile, can perform extraction and vacuum concentration.
- Can extract coffee, tea, Chinese medicine, herbs, natural products.
- Datasheet
- Video
| Sr.no | Parameter | Pilotech YC-200 Herb Extractor |
| 1 | Power Supply | Three-phase five-wire; 48KW. |
| 2 | Voltage | 380V |
| 3 | Extraction tank volume | 200L |
| 4 | Machine Material | SUS 304 Stainless Steel |
| 5 | Evaporation chamber vacuum degree | 0~-0.08MPa |
| 6 | Precision of temperature | ±2℃ |
| 7 | Cooling water | 3.5t/h |
| 8 | Cooling water pressure | ＜0.3pa |
| 9 | Coiled tube condenser area | 3㎡ |
| 10 | Dimension | 2250*1000*2500 mm(Reference Size) |
| 11 | Configuration | Stainless steel extractor（200L), Tube array condensator, coiled tube condenser, oil-water separator, pipeline sight glass, Stainless steel water ring pump, Omron temperature controller, Stainless steel extract blue, electric heater, Sanitary safety valve, control cabinet, connection with pipe Tube Fitting Valve |
Pilotech Related Products
Complete Guide
to YC-200 Herb Extractor FAQs
What is the volume of YC-200 Herb Extractor?
The volume of YC-200 Herb Extractor is 200L.
What materials are used to make the YC-200 Herb Extractor?
YC-200 Herb Extractor is made of SUS304 stainless steel.
What is the heating power requirement for YC-200 Herb Extractor?
The heating power requirement is 380V, three-phase five-wire, with a total power of 48 KW.
How much cooling water is consumed by the system of YC-200 Herb Extractor?
The system consumes cooling water at a rate of 3.5/h, with a pressure of less than 0.3 MPa.
Does the YC-200 Herb Extractor come with a concentration tank?
Yes, YC-200 herb extractor is equipped with a concentration tank, which has high concentration efficiency and a concentration ratio of 1.1 to 1.38.
What is the warranty period for YC-200 Herb Extractor?
Pilotech YC-200 Herbal Extractor comes with a one-year warranty, and extended warranties are available.
How can I purchase YC-200 Herb Extractor?
You can purchase YC-200 Herb Extractor by contacting our sales team directly via email, phone or the inquiry form on our website. Our team will get back to you with a solution as soon as possible.
