Small Beverage Dairy Production Line
- Small dairy production equipment.
- Modular design, simple installation and easy use.
- 20L/H rated capacity, other capacities are available.
- Completely simulated industrialization.
- No steam required, safer to use.
- Datasheet
- Video
Sr.no | Parameter | Small beverage dairy production line |
1 | Raw materials | fresh fruits, dairy products, concentrated juice, tea, etc. |
2 | Processing capacity | 20L/H. (Depending on the equipment model and configuration, the maximum fresh fruit processing capacity of the production line is 25 kg/hour; 50 kg/hour; 100 kg/hour; 200 kg/hour; 500 kg/hour) |
3 | Effective input | Effective input: 25 kg to 500 kg of fresh fruit/hour (5% waste, such as core and peel output) |
4 | Effective output | 20 kg to 300 kg of finished flavored juice |
5 | Juice ingredients | pure fruit juice, purified water, glucose and other flavored juice or pure juice drinks with various flavor additives |
6 | Sterilization method | pasteurization (sterilization pot), high temperature sterilization (sterilization kettle), ultra-high temperature sterilization (ultra-high temperature instant sterilizer) (select according to requirements) |
7 | Terminal packaging | 200ml~500ml glass bottle, PET bottle |
8 | Capacity | About 25~500 kg/hour, (select a suitable production line according to needs) |
Complete Guide
to Dairy Production Equipment
Pilotech Dairy Production Equipment is the result of nearly 20 years of research and innovation by the Pilotech R&D team. Combining the actual needs of food colleges, research institutes and food enterprise R&D departments, Pilotech has achieved modular design. Pilotech Dairy Production Equipment can be operated as a whole line or used independently. The rated capacity is 20L/H, and other specifications such as 50L/H can also be customized. It is very suitable for small-batch production in the early stages of various colleges, research institutes and food enterprises.
Pilotech Dairy Production Equipment is widely used in the original formula determination and update of milk, tea beverages, juices, jams, biopharmaceuticals, fruit drinks, condiments, beer, cream, ice cream, egg products, bean paste, bean paste and other products, product taste identification, color evaluation, stabilizer/emulsifier application, new product development and sample production.
Pilotech Dairy Production Equipment can fully simulate the production status of industrial sterilizers, online homogenizers, and aseptic filling machines. It integrates heating, sterilization, cooling, online homogenization, and aseptic filling, and can produce continuously. It is a good helper for scientific researchers in process exploration and new product development.
Process flow of successful products:
1. Apple juice production process:
Apples—fruit washing—fruit inspection—crushing—enzyme inactivation—juice extraction—filtration—sterilization—cooling—centrifugal separation—clarification—filtration—sterilization—aseptic storage—aseptic filling—labeling—inkjet printing—packaging
2. Hawthorn juice production process:
Hawthorn fruit—fruit washing—fruit inspection—crushing—softening—extraction—filtration—centrifugal separation—clarification—centrifugal separation—filtration—concentration—sterilization—aseptic filling—sealing—packaging
3. Ginkgo leaf juice production process:
Ginkgo leaf—washing—waxing—baking—crushing—extraction—filtration—removing astringency—blending—finished ginkgo leaf juice. (Ginkgo leaf juice is mainly used as an additive for fruit juice drinks, such as ginkgo leaf pear juice, ginkgo leaf tea juice drinks, etc.)
4. Production process flow of jujube and Ligustrum lucidum compound beverage:
1) Jujube – cleaning – baking – cleaning – pre-cooking – pulping – extraction – filtration – temporary storage;
2) Ligustrum lucidum – cleaning – crushing – extraction – filtration – temporary storage;
(1+2) blending – homogenization – sterilization – filling – tunnel sterilization – drying – packaging.
5. Production process flow of strawberry juice:
Fresh strawberries – cleaning – fruit selection – spraying – fruit inspection – preheating – juicing – filtration – clarification – filtration – blending – sterilization – aseptic filling – tunnel sterilization – cooling – drying – packaging.
Our Dairy Production Equipment can be disassembled and purchased separately. If you only need YC-02 UHT Sterilizer, homogenizer or filling machine, you can also contact us directly and our team will provide you with a solution.
If this is the Dairy Production Equipment you are looking for, what are you waiting for? Send an inquiry directly and the Pilotech team will tailor a solution only for you.
Pilotech Dairy Production Equipment is a modular system designed for small batch production. It integrates heating, sterilization, cooling, homogenization and aseptic filling, fully simulating industrial processes.
The standard rated capacity is 20L/H. If you require other specifications, such as 50L/H, other specifications are available upon request.
Yes, it is used for a wide range of food and beverage products, including milk, tea drinks, juice, jam, beer, ice cream, and even biopharmaceuticals.
Yes, you can purchase individual components such as the YC-02 UHT Sterilizer, homogenizer, or filling machine according to your specific needs.
Yes, Pilotech dairy production equipment has integrated aseptic filling capabilities and is ideal for producing high-quality sterile products.
Yes, Pilotech dairy production equipment is ideal for producing a variety of juices such as apple juice, hawthorn juice, ginkgo leaf juice, strawberry juice, etc.
Yes, Pilotech dairy production equipment is well suited for producing tea beverages and other similar beverages.
The process involves steps such as washing, enzyme deactivation, extraction, filtration, sterilization and aseptic filling.
Simply send us an inquiry and our team will provide you with a tailor-made solution to meet your production needs.
We offer a standard one-year warranty for all our equipment.
Yes, we offer extended warranty options. Please contact our sales team for details on extending the warranty coverage.
Lead times depend on the specific equipment configuration and customization. Generally, it takes around 6-8 weeks for delivery after confirming the order.
