Pilot Scale Spray Dryer Model: YC-029
- Achieves up to 92% recovery rate.
- Particle sizes from 1 to 120 microns.
- Color LCD touch screen for easy operation.
- Only 200mL of material to operate.
- Can handle heat-sensitive materials.
- Datasheet
- Video
| Sr.no | Parameter | Pilotech YC-029 Pilot Scale Spray Dryer |
| 1 | Power Supply | 20KW |
| 2 | Voltage | 380V; three-phase five-wire; 50-60 Hz |
| 3 | Capacity | Max. 10L/h |
| 4 | Rated airflow | 4m³/min |
| 5 | Heater power | 18000W |
| 6 | Max. Inlet temperature | 260⁰C |
| 7 | Compressed air | 128L/min |
| 8 | Nozzle type | Two fluid nozzle |
| 9 | Nozzle jet | 3mm standard |
| 10 | Possible particle size range | 1-120µm |
Advanced Nozzle Technology
The nozzle effectively converts liquids into fine droplets. Compressed air is delivered to the nozzle via an outer tube. Each unit comes with a 3.0 mm nozzle as standard, other sizes are available as optional accessories.
Enhancing Efficiency
The cyclone separator and collection tank can be easily installed and removed for easy cleaning. The cyclone separator can effectively separate the dry powder from the air. The collection tank can easily recover the product.
Color LCD Touchscreen
The touchscreen interface uses an LCD color touchscreen to easily adjust settings such as blower, peristaltic pump speed and heating. It also allows real-time adjustments and monitoring to maximize efficiency and minimize downtime.
Pilotech Related Products
Complete Guide
to YC-029 Pilot Scale Spray Dryer
YC-029 Pilot Scale Spray Dryer is developed by Pilotech based on 5L/H. Many customers feel that the effect is very good after using our 5L/h spray dryer, and want to buy a larger device from us. Later, we developed YC-029 Pilot Scale Spray Dryer, which has a maximum processing capacity of 10L/h.
The minimum air inlet temperature of YC-029 Pilot Scale Spray Dryer is 110℃, the maximum air inlet temperature is 280℃, and the particle size range that can be achieved is 1~120um.
The minimum sample size of the YC-029 Pilot Scale Spray Dryer is 200ml. With this pilot scale equipment, you no longer need to buy small laboratory equipment. YC-029 Pilot Scale Spray Dryer can also be used for small batch experiments.
YC-029 Pilot Scale Spray Dryer is highly efficient, with a recovery rate of up to 92%, ensuring that you get the most out of your materials with minimal waste.
It uses a 7-inch LCD color touch screen with Chinese and English languages. We can also customize your language according to your requirements. You can set the parameters on the touch screen to achieve the drying of the material.
YC-029 is mainly used for drying aqueous solutions, suspensions, and emulsions. If your material is heat-sensitive, such as biological agents, enzyme preparations, etc., you can use our YC-3100 vacuum low-temperature spray dryer with the same processing capacity.
Let’s take a look at the workflow of the YC-029 Pilot Scale Spray Dryer.
First, the liquid material enters through the feed pipe and is atomized into small droplets at the atomizer. The small droplets are in contact with the heated air for 1 second. The moisture on the surface of the small droplets is dried to form powder. Under the action of the cyclone separator, the powder is collected in the collection tank.
Technical Specifications
| Parameter | Pilotech YC-029 Pilot Scale Spray Dryer |
| Power Supply | 20KW |
| Voltage | 380V; three-phase five-wire; 50-60 Hz |
| Capacity | Max. 10L/h |
| Rated airflow | 4m³/min |
| Heater power | 18000W |
| Max. Inlet temperature | 260⁰C |
| Compressed air | 128L/min |
| Nozzle type | Two fluid nozzle |
| Nozzle jet | 3mm standard |
| Possible particle size range | 1-120µm |
| Temperature precision | ±2⁰C |
| Max. Sample feed | 10000ml/hr |
| Min. sample volume | 200ml |
| Seal of cyclone/cylinder | Silicone |
| Spray chamber material | SUS-304 Stainless steel |
| Body material | SUS-304 Stainless steel |
| Receiving tank material | SUS-304 Stainless steel |
| Cyclone separator material | SUS-304 Stainless steel |
| Weight | 490kg |
| Dimensions | 1650*1100*2530mm |
| Display | 8-Inch LCD display for Heat, Spray, Pump, Air pressure, de-blocker frequency |
| Atomizer material | SUS-316 Stainless steel |
| Deblocking | Automatic |
Contact Pilotech today to learn more about YC-029 Pilot Scale Spray Dryer and how it can help. Our team of experts is here to assist you with all your spray drying needs. Visit our website or reach out directly to speak with a representative. Let Pilotech be your partner in innovation and efficiency.
YC-029 Pilot Scale Spray Dryer has a maximum capacity of 10L/H, making it ideal for both small and medium-scale production runs.
Yes, YC-029 Pilot Scale Spray Dryer is designed to process heat-sensitive materials such as biologics and enzymes. With a minimum inlet temperature of 105°C and precise temperature control, you can dry sensitive materials without compromising their integrity.
YC-029 Pilot Scale Spray Dryer can operate with a minimum sample volume of just 200 ml, allowing you to conduct small-scale testing without wasting precious materials.
YC-029 pilot-scale spray dryer can produce particles from 1 micron to 120 microns, providing flexibility to meet a variety of application needs.
All product contact parts of the YC-029 pilot spray dryer are made of 304 stainless steel to ensure durability and meet industry standards.
YC-029 pilot-scale spray dryer is versatile and can dry a wide variety of solutions, including aqueous solutions, suspensions and emulsions.
Yes, YC-029 Pilot Scale Spray Dryer comes with English interface by default, but we can customize the interface to support other languages upon request.
YC-029 Pilot Scale Spray Dryer is highly efficient, with a recovery rate of up to 92%, ensuring that you get the most out of your materials with minimal waste.
YC-029 pilot spray dryer comes with a one-year warranty, which you can also extend for a fee.
